▍Product Introduction
Pressure Testing and Cleaning Machine for Rubber Hoses developed by our company is a fully enclosed safety pressure rising pressure test and pressure maintaining system, providing high cleanliness, fast pressure rising speed, easy and safe connection, stability, and other features. And because of its excellent quality, high configuration, fast pressure rising speed, this Pressure Testing and Cleaning Machine is Not only used as experimental testing equipment, but also can be used for long-term production. Then you can test every hose assembly into a hassle-free, fast affair.
Our Pressure Testing and Cleaning Machine is a water test bench up to 1000 BAR, for testing both hydraulic medium and high pressure hoses from 150bar up.
ALL the operation of Water injection, pressure rising, pressure maintaining, pressure relief, drainage, cleaning is AUTOMATIC
Operation: Simply connect one of our hydraulic testing systems to the workshop air source to complete a safe high-pressure test with a hydraulic testing output pressure of up to 1000bar.
We also can make customized testing pressure up to 1500-2000bar.
▍Product Advantages
High volume production
Can continuous test >700 hoses per day
High-grade configuration
Test and clean hose
Integrated function of pressure testing, pressure maintaining, cleaning and blowing
▍Product Features
Series production, can test at least 700 hoses per day
Accurate pressure test data, stable testing pressure
High degree of automation: One click start
Easy installation of hose joints, low consumables, and low losses
Integrated function of pressure testing, pressure maintaining, cleaning and blowing
Safe and closed operation, Full closed system
Multiple hoses can be connected in series, and the ability to continue production
Fast pressure boosting speed
Water system circulation, self-cleaning
Combining MEX system for data collection
Equipped with separate cleaning and water blowing functions, capable of performing multiple low-frequency pulse cleaning functions (can be configured to enhance the blowing intensity to 2-10MP)
▍Product Details
▍Optional Configuration
▍Technical Parameters
Equipment Objectives | Medium and high-pressure hoses: the inner diameter of the hose is from Ø6 to Ø25 |
Funcation | 1. The cleaning, pressure rising, pressure testing, pressure maintaining, water release, and air blowing processes are all automatically implemented.
2. It can operate in two modes: separate cleaning function and integrated function.
3. It can perform multiple low-frequency pulse cleaning functions and enhance the blowing force to 2MP |
Test pressure | 15-75MPa, with a maximum pressure up to 100MPa; |
Max test pressure | 150-200MP |
Pressure rising time | 40 seconds to rise to 100MPa |
Pressure maintaining time | 10-180 seconds |
Number of hoses can be connected | Multiple assembly hoses can be connected |
Power supply | AC380V, 50Hz, 3-phase, 5-wire |
Capacity of water tank | 100-150L |
Structure of water tank | The water tank is divided into two sections, with the outlet water tank on one side and the return water tank on the other (it can also be regarded as the clean water area and the dirty water area). |
