Automatic Hydraulic Hose Head Reverse Cleaning Machine

Automatic reverse cleaning
Wide hose cleaning range
The cleaning-liquid is circulated and filtered
Adjustable cleaning-liquid temperature
Water clean and air blowing switch
Type: single hose and three hoses cleaning

Quantity:
Availability:





Inquire Add to Basket

Product Description

▍Product Introduction

Hose head cleaning machine is used to clean rubber hoses. Insert one end of the hose assembly to be cleaned into the nozzle that matches its diameter, and you can freely switch between cleaning and blowing (compressed air blowing to remove residual water from the inner wall of the hose). The cleaned cleaning solution can be recycled and reused after being filtered. And the cleaning solution can be heated to remove insoluble impurities and oil stains.

▍Product Features

High degree of automation: Hose end induction automatic Reverse cleaning, adjustable pressure and cleaning time
Reverse cleaning
Wide cleaning range: hose diameter Ф 8-- Ф 50
The cleaning liquid is recycled and equipped with a filtering and cleaning device
Adjustable temperature of cleaning liquid for the hose body
The cleaning operation can be switched between water and air for blowing and cleaning
Convenient and reliable replacement of spray nozzle tooling
Type: single hose cleaning machine and three hoses cleaning

▍Product Details

▍Optional Configuration

▍Technical Parameters

Cleaning objects	Various types of hose heads
Inner diameter specifications	Ø8~Ø50
Working process	1. Reverse cleaning of the inside of the pipe body using a spray nozzle 2. Replace different spray nozzle fixtures according to different pipe body specifications
High-pressure pump flow rate	16.9L/min
Discharge pressure	4MPa
Motor	1.5-2.2KW×4P×AC380V
Cleaning time and frequency	0~20 seconds
Power supply	AC380V 3-phase 4-wire 50Hz
Noise value	Below 75dB for each individual device
Water temperature control	50-60℃ (optional)
