▍Product Introduction
The FH5 hose steel wire bobbin winding machine developed by our company is an upgraded product from the original FH5 bobbin winding machine. This equipment is a high-performance equipment independently designed and developed, and our company has a design patent for this equipment.
The machine steel wire bobbin winding machine adopts a complete set of Siemens system, with fast reaction speed, stable performance, and high degree of automation. The take-up adopts Siemens frequency converter, and the take-up motor also uses Siemens motor to ensure stable take-up and stable speed. The pay-off mechanism adopts single station independent servo control, and Siemens servo is used for both wire arrangement and pay-off to achieve stable and reliable performance indicators.
At the same time, the pay-off mechanism adopts constant tension control to ensure that the tension of each steel wire strand is consistent, in order to obtain performance indicators (Overall wire distance) that meet international standards. The controller adopts Siemens PLC, with processing time and response speed comparable to ordinary brands. In addition, the high-end sensors of the pay-off mechanism have led the automation level of the entire system to the same type of equipment abroad.
▍Product Advantages
Bobbin winding machine main machine
Adopting independent wire laying control and tension adjustment methods for each strand to ensure stable wire pay-off and achieve good overall wire distance; Adopting high-precision ball screw and Siemens servo motor to achieve stable wiring arrangement; The winding adopts independent Siemens AC motor control to achieve stable and balanced winding speed.
Electrical control system
The electrical control system of this machine uses high standard and high-quality components. The host adopts a high-end Siemens control system, and the main control part adopts Siemens PLC and touch screen control, achieving human-machine dialogue. It fully considers the process, accuracy, safety, and maintenance aspects, and has the advantages of smooth and reliable operation of the entire automatic control part, good repeat performance, low failure rate, and is equipped with alarm function, providing convenience for solving faults, fully meets the requirements of the entire production process for electrical control.
▍Product Features
Stranding speed up to 500m/min
High degree of automation
Electrical integrated design for easy operation
Adopts a complete set of Siemens system with stable performance
Stable take-up and stable rotation speed
Overall wire distance meets international standards
Siemens PLC, with processing time and response speed
Pay-off mechanism with the high-end sensors
▍Product Details
▍Optional Configuration
▍Technical Parameters
Spool | The specifications of the spool can be adjusted according to
customer needs |
Number of stranding | Can be customized according to customer needs |
Stranding speed | 500 meters/minute (maximum) |
Overall power | 16KW |
Overall dimensions | 4200 * 1600 * 2000 mm |
Weight | 2 tons |
Air pressure source | ≥ 0.4Mpa |
